HIKMICRO HIKTac TC19L Thermal Sight – 256×192 – Laser Rangefinder

HIKMICRO HIKTac TC19L Thermal Sight with Laser Rangefinder

The HIKMICRO HIKTac TC19L is a compact and lightweight thermal sight with an integrated laser rangefinder. It allows you to detect heat sources in complete darkness while measuring the distance to the observed object directly through the device.

The TC19L features a 256×192 thermal sensor with a 12 μm pixel pitch and thermal sensitivity of less than 18 mK. This enables the device to display small temperature differences clearly. Combined with the 19 mm F1.0 lens and low 1.2× base magnification, it provides a wide field of view for quickly scanning the surrounding area.

Integrated Laser Rangefinder

The main difference between the HIKTac TC19L and the TC19 is the integrated laser rangefinder. It can measure distances up to 1,000 metres with a stated accuracy of ±1 metre. This eliminates the need for a separate rangefinder and allows the measured distance to be viewed together with the thermal image.

Smooth 50 Hz Thermal Imaging

A 50 Hz refresh rate provides smooth imaging when observing moving heat sources. HIKMICRO combines several imaging technologies in the TC19L, including Image Pro 3.0, Zoom Pro, HSIS and Sync Pro. These technologies help maintain image detail while keeping image latency low.

The 1.2× base magnification provides a wide view of the surroundings. Digital zoom is available when a closer look is required, while the minimum focusing distance of approximately one metre allows the device to focus at short distances.

Large 3.1-inch AMOLED Display

The thermal image is displayed on a large 3.1-inch AMOLED screen, providing a clear view of detected heat sources and other displayed information. Different colour palettes, including White Hot, Black Hot, Red Hot and IronBow, allow the image to be adjusted to suit the conditions and personal preference.

Compact and Lightweight Design

Despite its integrated laser rangefinder, the HIKTac TC19L remains compact and lightweight. The IP67-rated housing provides protection against dust and water. Power is supplied by a replaceable and rechargeable 18650 battery.

The included killflash lens protector helps protect the objective lens while also reducing reflections from the front of the device.

Photo and Video Recording

The HIKTac TC19L can capture photos and record videos directly to its internal memory. Built-in Wi-Fi also allows the device to connect to the HIKMICRO Sight app, making it easy to view and transfer recorded footage.

Key Features

• 256×192 thermal sensor
• 12 μm pixel pitch
• Thermal sensitivity of <18 mK
• 19 mm F1.0 lens
• 1.2× base magnification
• Integrated laser rangefinder
• Rangefinder measuring distance up to 1,000 metres
• Distance measurement accuracy of ±1 metre
• 50 Hz refresh rate
• Minimum focusing distance of approximately 1 metre
• 3.1-inch AMOLED display
• Image Pro 3.0 and Zoom Pro
• HSIS shutterless imaging
• Sync Pro for low image latency
• Photo and video recording
• Built-in Wi-Fi
• Replaceable 18650 battery
• IP67 protection rating

Technical Specifications

Package Contents

• HIKMICRO HIKTac TC19L thermal sight
• Rechargeable 18650 battery
• Killflash lens protector
• USB-C cable
• Cleaning cloth
• Storage bag
• User manual

HIKMICRO HIKTac TC19L at SEM Jacht & Schietsport

The HIKMICRO HIKTac TC19L combines a sensitive thermal sensor, wide field of view and integrated laser rangefinder in one compact thermal sight. Compared with the TC19, the TC19L adds the ability to measure the distance to a detected object directly through the device.
