HIKMICRO HIKTac TC19 Thermal Sight – 256×192 Sensor – 19 mm Lens
HIKMICRO HIKTac TC19 Thermal Sight
The HIKMICRO HIKTac TC19 is a compact and lightweight thermal sight designed for situations where fast detection and tracking are important. Thermal imaging requires no ambient light, allowing heat sources to remain clearly visible in complete darkness and challenging visibility conditions.
The TC19 features a 256×192 thermal sensor with a 12 μm pixel pitch and thermal sensitivity of less than 18 mK. This allows the device to display even small temperature differences clearly. Combined with the 19 mm F1.0 lens, it provides a relatively wide field of view, making it particularly suitable for short to medium distances.
Fast and Smooth Thermal Imaging
A 50 Hz refresh rate provides a smooth image when observing moving objects. HIKMICRO combines several imaging technologies in the HIKTac TC19, including Image Pro 3.0, Zoom Pro, HSIS and Sync Pro. These technologies help provide a detailed thermal image with minimal image delay, making moving heat sources easier to follow.
The 1.2× base magnification provides a wide view of the surrounding area. Digital zoom is available when a closer view is required. With a minimum focusing distance of approximately 1 metre, the TC19 can also be used effectively at short distances.
Large 3.1-inch AMOLED Display
The thermal image is shown on a large 3.1-inch AMOLED display, providing a clear and comfortable view of detected heat sources. Different colour palettes, including White Hot, Black Hot, Red Hot and IronBow, allow you to adjust the image to suit the conditions and your personal preference.
Compact and Lightweight Design
Weighing less than 260 grams without the battery, the HIKTac TC19 is exceptionally compact and lightweight. Its IP67-rated housing provides protection against dust and water, while power is supplied by a replaceable and rechargeable 18650 battery.
The included killflash lens protector helps protect the objective lens while also reducing reflections from the front of the device.
Photo and Video Recording
The HIKTac TC19 can capture photos and record videos directly to its internal memory. Built-in Wi-Fi also allows the device to connect to the HIKMICRO Sight app, making it easy to view and transfer recorded footage.
Key Features
- 256×192 thermal sensor
- 12 μm pixel pitch
- Thermal sensitivity of <18 mK
- 19 mm F1.0 lens
- 1.2× base magnification
- 50 Hz refresh rate
- Minimum focusing distance of approximately 1 metre
- 3.1-inch AMOLED display
- Image Pro 3.0 and Zoom Pro
- HSIS shutterless imaging
- Sync Pro for low image latency
- Photo and video recording
- Wi-Fi connectivity
- Replaceable 18650 battery
- IP67 protection rating
- Weight below 260 grams without battery
Technical Specifications
| Sensor resolution | 256×192 pixels |
| Pixel pitch | 12 μm |
| Thermal sensitivity | <18 mK |
| Refresh rate | 50 Hz |
| Objective lens | 19 mm F1.0 |
| Base magnification | 1.2× |
| Digital zoom | Up to 8× |
| Detection range | Up to approximately 900 metres |
| Minimum focusing distance | 1 metre |
| Display | 3.1-inch AMOLED |
| Colour palettes | White Hot, Black Hot, Red Hot and IronBow |
| Internal storage | 4 GB |
| Wi-Fi | Yes |
| Protection rating | IP67 |
| Power supply | Replaceable rechargeable 18650 battery |
| Operating time | Up to approximately 4 hours |
| Weight | <260 g without battery |
Package Contents
- HIKMICRO HIKTac TC19 thermal sight
- Rechargeable 18650 battery
- Killflash lens protector
- USB-C cable
- Cleaning cloth
- Storage bag
- User manual
HIKMICRO HIKTac TC19 at SEM Jacht & Schietsport
The HIKMICRO HIKTac TC19 combines a sensitive thermal sensor, large display and compact design. Its low base magnification and short minimum focusing distance make it particularly useful when a wide field of view and fast detection of moving heat sources are important.
